INDIRECT DIRECT UNIT – IDU™

Industrial class indirect-direct cooling equipment lowers the supply air temperature by as much as 10°F

The IDU™ is United Metal Products' efficient indirect-direct cooling system. The IDU provides an energy efficient solution for facilities that need effective cooling, but find the operational expenses associated with A/C to be cost prohibitive as well as inefficient. One of the main advantages of the IDU is that it can provide a low discharge air temperature without the use of compressorized equipment. Indirect-direct cooling is also a more effective system than standard evaporative units in that it can lower the supply air temperature by as much as 10°F. For these reasons and more the IDU is an excellent option for industrial/commercial applications that require anywhere from 1,000 CFM up to 120,000 CFM.


FEATURES

  • 78 different cabinet sizes available
  • Available as indirect-only or as indirect -direct cooling module
  • Can be used as a stand-alone module or incorporated into an AHU with additional filtration, heating and supply air fan
  • Forward curved, airfoil or backward inclined wheels
  • 2” double wall or single wall construction
  • Galvanized, aluminum or stainless steel construction
  • Epoxy powder base paint finish baked on at 375°
  • Factory tested and shipped ready to operate, including factory wired component
  • Fan performance is factory set to job specifications
  • ETL listed and labeled in accordance with UL1995
  • Indirect-direct cooling has a smaller carbon footprint than A/C
  • CFC free (helping to achieve LEED certification)

  • 78 different cabinet sizes available
  • Available as indirect-only or as indirect -direct cooling module
  • Can be used as a stand-alone module or incorporated into an AHU with additional filtration, heating and supply air fan
  • Forward curved, airfoil or backward inclined wheels
  • 2” double wall or single wall construction
  • Heavy gauge galvanized, aluminum or stainless steel construction
  • Epoxy powder base paint finish baked on at 375°
  • Factory tested and shipped ready to operate, including factory wired component
  • Fan performance is factory set to job specifications
  • ETL listed and labeled in accordance with U.L. standards
  • Indirect-direct cooling has a smaller carbon footprint than A/C
  • CFC free (helping to achieve LEED certification)
